High Brightness P3.91 Transparent LED Panel / LED Display Screen Wall Waterproof IP42
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | VEGOO |
| Certification: | CE ROHS FCC |
| Model Number: | VG-SUN8887 |
| Document: | Product Brochure PDF |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Plywood case / Flight case / Carton box |
| Delivery Time: | 20-35 working days |
| Payment Terms: | T/T |
| Supply Ability: | 3000 sqm per month |
|
Detail Information |
|||
| Module Size: | 250*250mm | Module Resolution: | 64*32 |
|---|---|---|---|
| Input Voltage: | DC5V | Transparency Rate: | 55% |
| Module Power: | 25w | Cabinet Size: | 1000*500*65mm |
| Cabinet Resolution: | 128*128 | Cabinet Material: | Aluminum, PC, Stamping Parts |
| Cabinet Weight: | 7.5kg | Protection Grade: | IP42 |
| LED Specification: | Outdoor SMD1921 | Refresh Rate: | 2880Hz |
| Highlight: | transparent led video wall,transparent led panel |
||
Product Description
High Brightness P3.91 Transparent LED Panel Sales Transparent LED Display Screen Wall waterproof IP42
1. High Transparency
High resolution, it can be noticed when viewing from five meters or more.
2. Easy Installation
Super quick and easy for installation.
3. Light Weight
It weighs half of most LED displays.
4. High Brightness & Low consumption
It is visible under direct sun light and can be used 24/7.
5. Easy Maintenance and Operate
Good quality for long life expectancy (100,000 hrs). Replaced LED strips are swapped in easily and don't need to replace the entire panel.
Technical specifications:
|
P3.91MM |
|
| color | full color |
| transparency rate | 55% |
| module power | 25W |
| max consumption | 400W/㎡ |
| cabinet resolution | W256*H64 |
| input voltage | AC220V/(110V)±15%,47～63Hz |
| cabinet material | aluminum, PC, stamping parts |
| protection grade | IP42 |
| pixel pitch | H:3.9mm V:7.8mm |
| LED specification | OUTDOOR SMD1921 |
| pixel density | 32768 |
| scan mode | 1/16 |
| brightness(CD/m²) | 3500-4500 |
| working humidity | 10%～95%RH |
| working temperature | -20~50C° |
| working life | ≥30000H |
| signal transfer | Internet cable |
Our service :
1) After-sale technical guidance
For installation and use, please feel free to contact us at any time, we will reply within 24h.For large projects, we will provide free online video training for your engineers for a week. If necessary, we will arrange our engineers to do on-site guidance. (The relevent cost of on-site guidance will be borne by the customer)
2) Warranty
3 years.
3) Maintenance terms
If the product broken down during normal use and storage, our company will be responsible for maintenance during the warranty period and will bear all maintenance costs. If the warranty period has passed, only the material cost fee is charged, no other labor fee etc.
