P5 Full Color SMD HD Outdoor Taxi LED Display Easy Installation Advertising Sign
Product Details:
| Place of Origin: | China |
| Brand Name: | Vegoo |
| Certification: | CE/ROHS/FCC/ |
| Model Number: | VG-SUN88813 |
| Document: | Product Brochure PDF |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiate |
| Packaging Details: | Plywood case / Flight case / Carton box |
| Delivery Time: | 7-10 days |
| Payment Terms: | T/T |
| Supply Ability: | 3000 sqm per month |
|
Detail Information |
|||
| Product Name: | P5 Outdoor LED Display | Pixel Pitch: | 5mm |
|---|---|---|---|
| Material: | Aluminum Or Iron | Driving IC: | MBI5124 Or ICN 2038S |
| Moduel Size(L×W)mm: | 320×160 | Cabinet Size(L×W×H)mm: | 960×960×130 |
| Module Resolution: | 64×32 | Cabinet Resolution: | 192×192 |
| Density: | 40,000 Pixel/m2 | Driving Method: | 1/8 Scan |
| Brightness: | 6000cd/㎡ | Contrast: | 1000:1 |
| Highlight: | taxi rooftop advertising signs,taxi top digital signage |
||
Product Description
P5 Full Color SMD HD Outdoor Taxi TOP LED Display Easy Installation Advertising sign Mobile Taxi Roof LED Display
Our Core Advantage:
1:Remote Control
2:Cooling System Design
The air flow to inner space from the heading direction and then formed the air flow soon, two fans at the back of the display will pull the air which will make the equipment work more reliable in high temperature and high humidity environments.
Our product's feature:
1.Double-sided, wide viewing angle for more attention accessable.
2.High definition,high brightness,make it possible to see clearly even you are in strong sunlight.
3.Waterproof IP65,Anti UV, sulfide resistance, can be long-term used outdoor.
4.Three anti-protection: anti-corrosion, anti-static, moisture, shock, greatly improving the reliability of the product.
5.Customed available,chip ,driving IC and lamp type is optional.
6.Low consumption,save power energy.
7.Small order is accepted.
P5 Outdoor Full color LED Display Specification
| Product Name | Specification | ||||||||||
| Pixel Pitch | 5mm | ||||||||||
| Pixel Configuration | 1R1G1B/SMD2727 | ||||||||||
| Density | 40,000 pixel/m2 | ||||||||||
| Driving Method | 1/8 Scan | ||||||||||
| Driving IC | MBI5124 or ICN 2038S | ||||||||||
| Brightness | 6000cd/㎡ | ||||||||||
| Brightness Adjustment | Auto and Manual | ||||||||||
| Power Consumption | Max Power:＜750W | ||||||||||
| Average power: ＜225W | |||||||||||
| Module Weight | 0.28kg | ||||||||||
| Color Temperature | 9500K—11500K | ||||||||||
| Horizontal Viewing Angle | 140º | ||||||||||
| Vertical Viewing Angle | 140º | ||||||||||
| Signal Processing | 10 or 14bit | ||||||||||
| Grey Processing | 1024×1024×1024 16834×16834×16834 |
||||||||||
| Control Distance | cable100m,Multimode500m,Single mode 2km | ||||||||||
| Frame Frequency | 65 Hz | ||||||||||
| Refresh Rate | >1920Hz | ||||||||||
| Control Mode | Synchronous/Asynchronous | ||||||||||
| The Opposite Calibration Curve | With Eight Optional Gamma Calibration Curve | ||||||||||
| Users can choose the recommended curve or adjust it based on actual situation | |||||||||||
| MTBF | >50000 hours | ||||||||||
| Life Span | 100,000 Hours | ||||||||||
| Operating Temperature | Working : -20 - 65 ℃ | ||||||||||
| Storage : -40 - 85 ℃ | |||||||||||
| Environment Temperature | -30℃ to 60℃; humidity Rh10% to 95% | ||||||||||
| Self-checking Technique | Self-inspection, communication test, power test, temperature monitoring (Be customized) | ||||||||||
| Operating System Platform | WindowsNT,Windows2000,WindowsXP,Windows7 | ||||||||||
| Power Supply | AC 85-264V | ||||||||||
quality+Reasonable price+Responsible After Service=Successful & Win
Products exchanged or returned :
we supply our products strictly according to the contract list , if the quantity or specification doesn't meet our contract list, the buyer can give objections within 3 days after received the products , we’ll exchanged after company confirmed.
Casual damage situation:
We can provide corresponding fittings without extra fee when improper operation or unexpected artificial damaged arise .
Over Guarantee time :
You only have to pay maintenance cost such as labor costs , spare parts costs and round-trip costs !
