Advertising SMD Rgb P8 Outdoor Full Color LED Display
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | VEGOO |
| Certification: | CE ROHS FCC CCC |
| Model Number: | VG-P8-DH |
| Document: | Product Brochure PDF |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 SQM |
|---|---|
| Price: | negotiate |
| Packaging Details: | flight case,plywood case,carton |
| Delivery Time: | 15-30 working days |
| Payment Terms: | T/T |
| Supply Ability: | 3000 sqm per month |
|
Detail Information |
|||
| Pixel Pitch: | 8mm | Module Size: | 320mm×160mm |
|---|---|---|---|
| Cabinet Size: | 960mm×960mm×130mm | Density: | 15,625 Pixel/m2 |
| Driving Method: | 1/ 5 Scan | Cabinet Resolutio: | 120×120 |
| Highlight: | P8 led outdoor display screen,SMD waterproof led screen,Rgb led panel screen outdoor |
||
Product Description
P8 Outdoor Full Color SMD Rgb Advertising LED Display Screen screen wall
| P8 Outdoor Full color LED Display Specification | ||||||||||||
| NO: | Product Name | Specification | ||||||||||
| 1 | Pixel Pitch | 8mm | ||||||||||
| 2 | Pixel Configuration | 1R1G1B/SMD3535 | ||||||||||
| 3 | Density | 15,625 pixel/m2 | ||||||||||
| 4 | Moduel Size(L×W)mm | 320mm×160mm | ||||||||||
| 5 | Cabinet Size(L×W×H)mm | 960mm×960mm×130mm | ||||||||||
| 6 | Module Resolution | 40×20 | ||||||||||
| 7 | Cabinet Resolution | 120×120 | ||||||||||
| 8 | Driving Method | 1/ 5 Scan | ||||||||||
| 9 | Driving IC | FM6124 | ||||||||||
| 10 | Brightness | 5500/㎡ | ||||||||||
| 11 | Contrast | 6000 :1 | ||||||||||
| 12 | Brightness Adjustment | Auto and Manual | ||||||||||
| 13 | Power Consumption | Max Power: ＜760 | ||||||||||
| 14 | Average power: ＜350W | |||||||||||
| 15 | Cabinet Weight | 25kg | ||||||||||
| 16 | Color Temperature | 2000K—9500K | ||||||||||
| 17 | Horizontal Viewing Angle | 140º | ||||||||||
| 18 | Vertical Viewing Angle | 140º | ||||||||||
| 19 | Signal Processing | 16bit | ||||||||||
| 20 | Grey Processing | 1024×1024×1024 16834×16834×16834 |
||||||||||
| 21 | Control Distance | cable100m,Multimode500m,Single mode 2km | ||||||||||
| 22 | Frame Frequency | 65 Hz | ||||||||||
| 23 | Refresh Rate | >1920Hz | ||||||||||
| 24 | Control Mode | Synchronous/Asynchronous | ||||||||||
| 25 | The Opposite Calibration Curve | With Eight Optional Gamma Calibration Curve | ||||||||||
| 26 | Users can choose the recommended curve or adjust it based on actual situation | |||||||||||
| 27 | MTBF | >50000 hours | ||||||||||
| 28 | Life Span | 100,000 Hours | ||||||||||
| 29 | Operating Temperature | Working : -20 - 65 ℃ | ||||||||||
| 30 | Storage : -40 - 85 ℃ | |||||||||||
| 31 | Environment Temperature | -30℃ to 60℃; humidity Rh10% to 95% | ||||||||||
| 32 | Remote Control | Can realize remote control and send alarm signal to operators in case of logging failure (Be customized) | ||||||||||
| 33 | Self-checking Technique | Self-inspection, communication test, power test, temperature monitoring (Be customized) | ||||||||||
| 34 | Operating System Platform | WindowsNT,Windows2000,WindowsXP,Windows7 | ||||||||||
| 35 | Power Supply | AC 110-220V/5V60Hz | ||||||||||
| 36 | Protection | waterproof, dustproof, high temperature pervention, anticorrosion, smoulderproof, anti-static, shockproof, lightningproof, smoke alarm and temperature alarm. (Be customized) | ||||||||||
FAQ
1. What about LED Display MOQ?
1sqm.
2.How about payment?
3.How about the lead time?
LED Module:1-7working days
LED Display: 7-20working days
4. How about the warranty time?
Our standard is 2years.
But you are willing to pay extra money for after sales and adopt industry top quality material,we can accept 3-5years warranty.
5. Which shipping port you use?
Our standard is Shenzhen port,but Guangzhou or Hongkong.
We also can accept your appoint port.
6. How to do the shipping?
You can use our shipping agent who we have cooperate more than 4years
Or you can use your shipping agent.
7. What`s trade terms you accept?
We accept EXW,CIF,FOB
Want to Know more details about this product
