SMD 3535 Advertisement P8 625nm LED Display Screen
Product Details:
| Place of Origin: | China |
| Brand Name: | Vegoo |
| Certification: | CE |
| Model Number: | VG-P8-DH |
| Document: | Product Brochure PDF |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1sqm |
|---|---|
| Price: | 600USD/Sqm |
| Packaging Details: | Plywood case / Flight case / Carton box |
| Delivery Time: | 10-20 days |
| Payment Terms: | T/T |
| Supply Ability: | 5000 Sqm/month |
|
Detail Information |
|||
| Pixel Pitch: | 8mm | LED Specification: | SMD 3535 |
|---|---|---|---|
| Working Voltage: | DC 5V | Color: | Full Color |
| Highlight: | 625nm LED Display Screen,P8 ultra thin led display,SMD 3535 LED Display Screen |
||
Product Description
Wholesale High Brightness P8 Outdoor Big Advertisement LED Display Screen
| P8 Outdoor Full Color LED Display Parameter | ||||
| (1)Parameter of Pixel | ||||
| Number | Item | Parameter | ||
| 1 | Pixel Pitch | 8mm | ||
| 2 | Pixel composition | 1R1G1B | ||
| (2)Parameter of Chip | ||||
| Number | Item | Wave length | Brightness | Specification |
| 1 | Red Chip | 621-625nm | 550-688mcd | SMD 3535 Lamp |
| 2 | Green Chip | 520-524nm | 1050-1312mcd | |
| 3 | Blue Chip | 466-470nm | 160-200mcd | |
| (3)Display Technical Parameters | ||||
| Lamp | LED Specification | SMD 3535 | ||
| Module | Module Size | W256mm*H128mm | ||
| Module Resolution | W32 Dots*H16 Dots/40Dots*H20Dots | |||
| Scanning Mode | 1/4 | |||
| Working Voltage | DC 5V | |||
| Module Power | 30W | |||
|
Cabinet
|
Standard Size | 1024*1024mm | ||
| Ingress Protection | IP65 (Front) /IP65 ( Rear) | |||
| Cabinet Resolution | 128*128 Dots | |||
| Cabinet Material | Diecast Cabinet/Simple Iron Cabinet | |||
| 4 | LED Driver | Constant Current | ||
| 5 | Pixel/ M2 | 15625 Dots/ M2 | ||
| 7 | Display Brightness | Maximum 7200cd/ M2 | ||
| 8 | Viewing Angle | Horizontal 160° Vertical 140° | ||
| 9 | Best Viewing Distance | ≥8m | ||
| 10 | Grey Level | Red,Green,Blue each 256 Levels of Grey | ||
| 11 | Display Color | 16.7M | ||
| 12 | Color Quality | 32 Bits | ||
| 13 | Frame Changing Frequency | >60(Frames)/s | ||
| 14 | Refresh Rate | >1920HZ | ||
F&Q
Q1:How could I buy the products I need if there is no price in the website?
A: You can send your inquiry to us about the products you need,our sales will reply you within 24 hours to help you make the order.
Q2:How long could I get reply of my inquiry?
A:You will get a reply within 24 hours.
Q3: What kind of warranty do you offer?
A: Different product offer different time frame warranty, but all product here we offer 2 year at least warranty.
Q4:How is the after sales service?
A: We have a professional team which is in charge of after-sales service, also a service hot-line dealing with your complains and feedback.We also offer 24-hour online service to help you solving problems.
Q5:What kind of payment methods do you have as a manufacturer?
A: We take T/T .
Q6:How long will it take to deliver goods?
A: We will start preparing goods when we get your bank receipt. The package will be shipped out in 10-15working days after we get your payment.
Q7: What kind of packaging you offer?
A: During the packaging process, preventive measures will be taken by us to assure that the goods are in a good condition during storage and delivery.
