Commercial Front Service DIP P16 Outdoor Full Color LED Display

Commercial Front Service DIP P16 Outdoor Full Color LED Display

Product Details:

Place of Origin: China
Brand Name: Vegoo
Certification: CE
Model Number: VG-P16-DH
Document: Product Brochure PDF

Payment & Shipping Terms:

Minimum Order Quantity: 1sqm
Packaging Details: Plywood case / Flight case / Carton box
Delivery Time: 10-20 days
Payment Terms: T/T
Supply Ability: 5000 Sqm/month
Get Best Price Contact Now

Detail Information

Pixel Pitch: 16mm Size Of Module: 320mm*320mm
Density: 3906 Dots/㎡ Size Of Cabinet: 1280mm*960mm
Highlight:

P16 outdoor advertising display

,

DIP outdoor rental led screen

Product Description

P16 Outdoor Fixed Installation LED Display for Commercial Advertising Front Service DIP LED



Features:

1. Lamps adopts unique packing technology, with high brightness and high protection characteristics.
2. Flexible user-defined cabinet size help provide a more suitable & economical solution.
3. Standardized design, versatility, fast and easy installation and maintenance.
4. High level of protection and stability, which is suitable for a variety of outdoor harsh environment.
Parameters
Pixel pitch
16mm
LED type
DIP346
Pixel configuration
1R1G1B
Size of module
320mm*320mm
Resolution of module
24*24
Density
3906 dots/㎡
Cabinet material
Die-casting Aluminum
Size of cabinet
1280mm*960mm
Weight of cabinet
27.5KG/㎡
Support hanging or not
YES
Best viewing distance
>16m
Best viewing angle
140°
Max power consumption
350W/㎡
Average power consumption
120W/㎡
Colors
16.7M
Gray scale
16bits
Color temperature
3000-1000K
Driving method
static scanning
Refresh frequency
1920Hz
Frame frequency
60Hz
Control method
Synchronization
Driving device
Constant current
Brightness
8000cd/㎡
Working voltage
AC220V/110V±10%
Working temperature
-20℃~50℃±10%
Out-of control point
<0.0001
Brightness control
256 grade
IP grade
IP65
Mtbf
10,000Hours
Life span
100,000Hours
