Seamless Splicing 3.91mm Pixel Pitch Outdoor LED Display for Rental Screens 560g
Product Details:
| Place of Origin: | China |
| Brand Name: | VEGOO |
| Certification: | CE ROHC FCC |
| Model Number: | VG-P3.91-16scan |
| Document: | Product Brochure PDF |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Cabinet |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Wooden box or Flight case |
| Delivery Time: | 15-25days |
| Payment Terms: | T/T |
| Supply Ability: | 8000sqm per month |
|
Detail Information |
|||
| Module Size: | 250mmx250mm | Pixel Resolution: | 64dots(W)*64dots(H) |
|---|---|---|---|
| Max Power: | 38W | Pixel Density: | 65536dots/m2 |
| Module Thickness: | 16mm | Weight: | 560g |
| Drive IC: | ICND2153 | Brightness Of White Balance: | 6000cd/m2 |
| Input Voltage: | 110-220V;AC±10% | ||
| Highlight: | Seamless Splicing Outdoor LED Display,3.91mm Pixel Pitch Outdoor LED Display,Rental Outdoor LED Display |
||
Product Description
The advantages of rental screens:
1. Wide viewing angle, high contrast, seamless splicing, and high image quality
LED rental screens should have the functions of "beautiful appearance, lightweight, easy to carry, and stable quality", as well as wide viewing angle, high contrast, smooth patches, and high definition. Especially for LED rental screen casings used in the stage and entertainment industry, they are mostly made of aluminum boxes, with a weight of around 20-30 kilograms/m2. They are lightweight, ultra-thin, and easier to disassemble.
2. Long lifespan
The main component that affects the lifespan of LED rental screens is light-emitting diodes (LEDs). High temperature is the natural enemy of LEDs, and aluminum boxes have good thermal conductivity, which can stabilize environmental temperature and greatly extend the lifespan of display screens.
3. Good stability
The strengthening of the stability of LED rental screens is also one of the important factors widely accepted by most businesses. LED rental screens are often used for large-scale events such as advertising, performances, gatherings, and press releases, and their stability plays an important role throughout the entire process. Therefore, when selecting materials, enterprises will conduct relevant tests with requirements higher than industry standards to ensure long-lasting display effects. The improvement of control systems cannot be ignored in stable performance maintenance.
Technical Parameters
|
Unit Module |
Item |
Parameter |
|
| Model Number | VG-P3.91- 16S | ||
| Module Size | 250mm*250mm | ||
| Physical Pitch | 3.91mm | ||
| Physical Density | 65536 dots/m2 | ||
| Pixel Configuration | 1R1G1B | ||
| LED Package Mode | SMD 3IN1 - 1921 | ||
| Pixel Resolution | 64dots(W)*64dots(H) | ||
| Max Power | 38W | ||
| Module Thickness | 16mm | ||
| Weight | 560g | ||
| Drive Type | Constant Drive | ||
| Scan Mode | 1/ 16scan | ||
| Port Type | HUB75 | ||
| Match Cabinet |
W500mm*H500mm W500mm*H1000mm |
||
|
Display Parameters |
Dimension | 500mm*500mm |
| Thickness | 87mm | |
| Weight | 8kg | |
| Monomer Module Number | 4pcs | |
| Maintenance Connection Mode | Maintenance from the Back | |
| Pixel per Cabinet | 32768 pixels | |
| Best Viewing Angle | H:120°;V:120° | |
| Recommended Viewing | 4m-30m | |
| Driver IC | ICND2038S/2153/5124 | |
| Refresh Rate | 3840Hz | |
| Brightness of White Balance | 6000cd/㎡ | |
| Operating Temperature/Humidity | -20℃ ~ +50℃ | |
| Life Time | > 100000 hours | |
| Bad Light Rate | <0.0001 | |
| MTBF | >5000 hours | |
| Cabinet Matching Module Size | 250mmx250mm | |
| Cabinet Matching Module Model | P2.6/P2.97/P3.91/P4.81 | |
|
Power |
Input Voltage | 110-220V;AC±10% |
| Power Supply | 5V/60A*1 pcs | |
| Working Voltage | 110V-220V AC±10% | |
| Average Power Consumption | 260w/㎡ | |
| Max. Power Consumption | 800w/㎡ | |
|
Control system |
CPU | Pentium4 or Above |
| Operation System | WIN98/2000/NT/XP/WIN7 | |
| Control Method | Synchronization |
Detail Images
