HD Advertising 3840Hz P1.25 LED Stage Video Wall Display
Product Details:
| Place of Origin: | China |
| Brand Name: | Vegoo |
| Certification: | CE |
| Model Number: | P1.25-DH |
| Document: | Product Brochure PDF |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1sqm |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Plywood case / Flight case / Carton box |
| Delivery Time: | 10-20 days |
| Payment Terms: | T/T |
| Supply Ability: | 8000sqm/month |
|
Detail Information |
|||
| Pixel Pitch: | 1.25mm | Moduel Size(L×W)mm: | 200mm×150mm×8mm |
|---|---|---|---|
| Cabinet Size(L×W×H)mm: | 400mm×300mm×60mm | Brightness: | 600-800CD/㎡ |
| Refresh Rate: | >3840Hz | Horizontal Viewing Angle: | 140º |
| Highlight: | 3840Hz led advertising board,P1.25 pixel led panel |
||
Product Description
About Our Product:
1.Indoor p1.25 smd led display module is manufactured by using best quality material.
2.High refresh rate without flicker and distortion.
3.The final products are supreme quality and offers best outputs.
4.Light weight and easy to install
5.Single-lamp maintenance with low cost.
| P1.25 Indoor Full color LED Display Specification | ||||||||||||
| NO: | Product Name | Specification | ||||||||||
| 1 | Pixel Pitch | 1.25 mm | ||||||||||
| 2 | Pixel Configuration | 1R1G1B/SMD1010 Black lamp | ||||||||||
| 3 | Density | 640,000 pixel/m2 | ||||||||||
| 4 | Moduel Size(L×W)mm | 200mm×150mm×8mm | ||||||||||
| 5 | Cabinet Size(L×W×H)mm | 400mm×300mm×60mm | ||||||||||
| 6 | Module Resolution | 160×120 | ||||||||||
| 7 | Cabinet Resolution | 320×240 | ||||||||||
| 8 | Driving Method | 1/30 Scan | ||||||||||
| 9 | Driving IC | MBI5153/ICN 2153/FM6353 | ||||||||||
| 10 | Brightness | 600-800CD/㎡ | ||||||||||
| 11 | Contrast | 4000 :1 | ||||||||||
| 12 | Brightness Adjustment | Auto and Manual | ||||||||||
| 13 | Power Consumption | Max Power:＜900W | ||||||||||
| 14 | Average power: ＜100-300W | |||||||||||
| 15 | Cabinet Weight | 4.2kg | ||||||||||
| 16 | Color Temperature | 2000K—9500K | ||||||||||
| 17 | Horizontal Viewing Angle | 140º | ||||||||||
| 18 | Vertical Viewing Angle | 140º | ||||||||||
| 19 | Signal Processing | 16bit | ||||||||||
| 20 | Grey Processing | 1024×1024×1024 16834×16834×16834 |
||||||||||
| 21 | Control Distance | cable100m,Multimode500m,Single mode 2km | ||||||||||
| 22 | Frame Frequency | 65 Hz | ||||||||||
| 23 | Refresh Rate | >3840Hz | ||||||||||
| 24 | Control Mode | Synchronous/Asynchronous | ||||||||||
| 25 | The Opposite Calibration Curve | With Eight Optional Gamma Calibration Curve | ||||||||||
| 26 | Users can choose the recommended curve or adjust it based on actual situation | |||||||||||
| 27 | MTBF | >50000 hours | ||||||||||
| 28 | Life Span | 100,000 Hours | ||||||||||
| 29 | Operating Temperature | Working : -10 - 60 ℃ | ||||||||||
| 30 | Storage : -40 - 85 ℃ | |||||||||||
| 31 | Environment Temperature | -10℃ to 60℃; humidity Rh10% to 90% | ||||||||||
| 32 | Remote Control | Can realize remote control and send alarm signal to operators in case of logging failure (Be customized) | ||||||||||
| 33 | Self-checking Technique | Self-inspection, communication test, power test, temperature monitoring (Be customized) | ||||||||||
| 34 | Operating System Platform | WindowsXP/7/8/10 | ||||||||||
| 35 | Power Supply | AC110-240V / 5V60Hz | ||||||||||
| 36 | Protection Level | IP 45 | ||||||||||
Application
1.Providing professional technology supporting
2.Instructing installation and remote control
3.Trainning workers for free
4.Providing free procurement services
5.Customer first is our service tenet
Q1.What's the production time of your LED display?
A1:Normal production time is 15-20 days but hot season maybe 15-25 days.
Q2.What's the warranty of your screen?
A1:3 years
Q3.What's your payment term?
A3:We accept T/T.30% deposit in advance,and 70% balance before delivery.
Q4.How to help customer to install screen?
A4:We can arrange engineer to go to your country and instruct installation
