Super Bright Large Rental P3.91 Indoor Full Color LED Display
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | VEGOO |
| Certification: | CE ROHS FCC CCC |
| Model Number: | VG-SUN88862 |
| Document: | Product Brochure PDF |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 SQM |
|---|---|
| Price: | negotiate |
| Packaging Details: | flight case,plywood case,carton |
| Delivery Time: | 15-30 working days |
| Payment Terms: | T/T |
| Supply Ability: | 3000 sqm per month |
|
Detail Information |
|||
| Pixel Pitch: | 3.91mm | Refresh Rate: | >1920Hz |
|---|---|---|---|
| Density: | 65,536 Pixel/m2 | Moduel Size: | 250mm×250mm |
| Cabinet Size: | 500mm×1000mm×90mm | Cabinet Resolution: | 128×256 |
| Highlight: | P3.91 smd led screen,Rental outdoor smd led display |
||
Product Description
Portable P3.91 Large Rental LED Screen Display Indoor For Exhibition Super Bright
Features:
- Hight refresh rate:Over 1920 Hz refresh rate to ensure the picture wrinkle-less,line-less and stable;
- Light weight: one person can lift with one hand, saving installation time;
- High brightness, and can be adjustable, meets the need of changing requirement of customer in environment;
- High thermal conductivity Alloy cabinet, better heat dissipation;
- Seamless connection:The aluminum die-casting technology,together white the hight-percision CNC procession, makes the precision reach±0.05mm so as to achieve seamless assembly;
- With video processor, the displaying effect is better, clear picture and no blink;
- qualified by CE,RoHS,FC;
- Cost saving for installation and maintenance, Hotplug in power supply;
P3.91 Indoor Full color LED Display Specification
| Product Name | Specification | ||||||||||
| Pixel Pitch | 3.91mm | ||||||||||
| Pixel Configuration | 1R1G1B/SMD2121 Black lamp | ||||||||||
| Density | 65,536 pixel/m2 | ||||||||||
| Moduel Size(L×W)mm | 250mm×250mm | ||||||||||
| Cabinet Size(L×W×H)mm | 500mm×1000mm×90mm | ||||||||||
| Module Resolution | 64×64 | ||||||||||
| Cabinet Resolution | 128×256 | ||||||||||
| Driving Method | 1/16 Scan | ||||||||||
| Driving IC | MBI5124 or FM6124 | ||||||||||
| Brightness | 1000cd/㎡ | ||||||||||
| Contrast | 1000:1 | ||||||||||
| Brightness Adjustment | Auto and Manual | ||||||||||
| Power Consumption | Max Power:＜480W | ||||||||||
| Average power: ＜240W | |||||||||||
| Cabinet Weight | 15kg | ||||||||||
| Color Temperature | 2000K—9500K | ||||||||||
| Horizontal Viewing Angle | 120º | ||||||||||
| Vertical Viewing Angle | 120º | ||||||||||
| Signal Processing | 16bit | ||||||||||
| Grey Processing | 1024×1024×1024 16834×16834×16834 |
||||||||||
| Control Distance | cable100m,Multimode500m,Single mode 2km | ||||||||||
| Frame Frequency | 65 Hz | ||||||||||
| Refresh Rate | >1920Hz | ||||||||||
| Control Mode | Synchronous/Asynchronous | ||||||||||
| The Opposite Calibration Curve | With Eight Optional Gamma Calibration Curve | ||||||||||
| Users can choose the recommended curve or adjust it based on actual situation | |||||||||||
| MTBF | >50000 hours | ||||||||||
| Life Span | 100,000 Hours | ||||||||||
| Operating Temperature | Working : -20 - 65 ℃ | ||||||||||
| Storage : -40 - 85 ℃ | |||||||||||
| Environment Temperature | -30℃ to 60℃; humidity Rh10% to 95% | ||||||||||
| Remote Control | Can realize remote control and send alarm signal to operators in case of logging failure (Be customized) | ||||||||||
| Self-checking Technique | Self-inspection, communication test, power test, temperature monitoring (Be customized) | ||||||||||
| Operating System Platform | WindowsNT,Windows2000,WindowsXP,Windows7 | ||||||||||
| Power Supply | AC 110-220V/5V60Hz | ||||||||||
| Protection Level | IP 45 | ||||||||||
FQA:
1. What is a pixel?
The minimum luminous pixel LED display, with ordinary computer monitor, said the "pixel" the same meaning;
2. How to deal with the faulty?
2. How to deal with the faulty?
Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%;Secondly, during the guarantee period, we will send new module with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
3. Can you offer a technical support ? Since it s my first time.... ?
We provide free training for our customer, teach client how to set up screens, make configuration of parameters, broadcast the videos through Nova star control systems, configure of video processor.
4. Can I use my own forwarder to transport the products for me?
4. Can I use my own forwarder to transport the products for me?
Yes, if you have your own forwarder in Shenzhen, you can let your forwarder ship the products for you. And then you will no need to pay the freight to us;
